Polyurethane Foam Insulation Pipe Hanger
A polyurethane foam insulation pipe hanger is a designed element that transfer the load from a pipe to the supporting structures. The load includes the weight of the pipe proper, the content that the pipe carries, all the pipe fittings attached to pipe, and the pipe covering such as insulation.
Description
Product description:
Sgeflex® polyurethane foam insulation pipe hanger is a designed element that transfer the load from a pipe to the supporting structures. The load includes the weight of the pipe proper, the content that the pipe carries, all the pipe fittings attached to pipe, and the pipe covering such as insulation. The four main functions of a pipe hanger are to anchor, guide, absorb shock, and support a specified load. Pipe hanger used in high or low temperature applications may contain insulation materials. The overall design configuration of a pipe hanger assembly is dependent on the loading and operating conditions.
Specification ：
Technical information：
|
Material |
Cross-linked closed cell polyolefin foam |
|
Size |
Custom |
|
Color |
Black |
|
Compression strength |
2.4Mpa |
|
Constant working temperature |
-100-150°C |
|
Density |
300kg/m3 |
|
Thermal conductivity |
0.042 W/(m.k) |
Application:
The pipe supports of air-conditioning frozen water pipes,refrigeration system pipes,domestic water pipes,process pipes and other kinds of pipes.
